Product Details:
|
| Warranty: | 3years | Free Installation Service: | NO |
|---|---|---|---|
| Application: | Home | Solar Panel Type: | Monocrystalline Silicon, Polycrystalline Silicon |
| Battery Type: | Lithium Ion | Controller Type: | MPPT |
| Mounting Type: | Ground Mounting Roof Mounting Carport Mounting | Load Power (W): | 3KW, 8KW, 6KW, 5kW, 10KW |
| Output Voltage (V): | 110~220V | Output Frequency: | 50/60HZ |
| Pre-sales Project Design: | Y | Battery Type: | Household Energy Storage |
| Port: | YANTIAN | ||
| High Light: | lifepo4 All In One Solar System,split phase All In One Solar System,10kw energy storage battery |
||
|
product
|
type
|
split phase
|
|
|
|
Battery Power (kwh)
|
10kwh,15kwh,20kwh,25kwh
|
|
|
|
Inverter Power (kw)
|
4kw 5 kw 6kw 8kw 10kw 12kw
|
|
|
battery module
|
Nominal voltage
|
51.2V
|
|
|
|
Nominal capacity
|
100AH
|
|
|
|
Size
|
602L*403W*200Hmm
|
|
|
|
Weinght
|
55KG
|
|
|
Inverter module
|
Size
|
602L*403W*650Hmm/602L*403W*760Hmm
|
|
|
|
Weight
|
73kg .76kg.80kg/102kg.104kg.113kg
|
|
|
|
service life
|
0.2C charge and discharge, 6000 times ≥80% initial capacity
|
|
|
|
cooling method
|
self-cooling
|
|
|
|
relative temperature
|
20%-95%RH
|
|
|
|
protection level
|
IP20
|
|
|
|
service life
|
＞15 years@25℃
|
|
|
|
charging temperature
|
0～45℃
|
|
|
|
storage temperature
|
-10～35℃, less than 6 months
|
|
|
|
communication method
|
RS485 RS232 CAN
|
|
|
|
Support Inverter Brands
|
Goodwe,Growatt,Victron,LXP,Sofar,Deye,Sarmatec,SREN,TBB,SMA,Jinlang, Wheatfield, Riyueyuan, Suzhou Jiaxun Natong
|
|
|
Remark
|
Battery warranty is 3~5 years, inverter warranty is 2~3 years
|
|
|
