Product Details:
|
| Product Name: | LifePO4 Lithium Battery Pack | Capacity: | 100ah/200ah |
|---|---|---|---|
| Chargeable: | Yes | Cycle Life: | 6000 Times 15years |
| Inverter Mached: | Solax，Deye，Goodwe，Growatt,Victron，Sofar，GMDE，etc | Storage Type: | -10~45℃ |
| Battery Type: | Power Cabinet Rack Batteries | Application: | Electric Power Systems |
| Size: | 430*442*222mm | Energy: | 5kwh/10kwh |
| Protection: | Built-in Smart BMS | Module/Protocol: | Support Customization |
| OEM/ODM: | Support Customization | ||
| High Light: | Lithium Iron Phosphate Battery 48V 100AH,Rechargeable Solar Rack Mount Battery,Base Station Lithium Iron Phosphate Battery |
||
| Type | Rack-Mounted | Custom | |
| Model | FBC-5KWH | FBC-10KWH | contact us |
| Voltage | 51.2v | 51.2v | |
| Capacity | 100ah | 200ah | |
| Energy | 5.12 Kwh | 10.24 Kwh | |
| Output power | 5.12 Kw | 5.12 Kw | |
| weight | 49.5Kg | 95.5Kg | |
| Dimension | 442*430*177 mm | ||
| Warranty | 5 Years | ||
| Cycle Life | 6000 Cycles, 20 years design life | ||
| Inverter Matched | Solax, Deye, Goodwe, Growatt, Victron, Sofar, GMDE, etc. | ||
| Communication | RS485 /CAN option | ||
Attractive Design
FBC Lithium battery has compact design, LCD screen, convenient setting buttons, bluetooth Monitor on your smartphones, and
cables&accessories ready for installation.
To welcome the world cooperation we accept OEM with your logo design!
Wide Application
FBC Lithium Powerwall series are widely used in Solar Systems for residential and commercial use. With more than 6000 times
deep cycle, up to 90% DOD and phosphate battery Cell, FBC Powerwall has won global approval!
FBC reserves sole and only right for sales of it's powerwall.
Integrated Function
FBC Powerwall can be installed in parallel with combiner box for protection, with it's integrated BMS communication protocol to
comprehensive hybrid and off grid inverters!
50kwh 100kwh can be combined as needed
A single battery is 48v 200ah 10.24kwh.
A whole cabinet is 5 batteries, a total of 51.2kwh
If without master control, it support max 5 parallels for highest 51.2Kwh battery system; If with standard master controls, it
can be paralleled and serialed with more batteries.
