Product Details:
|
| Battery Type: | LiFePO4 | Product Name: | Lithium Battery Pack |
|---|---|---|---|
| Battery Size: | 12V 200AH | Battery Cell: | Lifepo4 |
| Cycle Life: | 4000 | Protection: | Built-in Smart BMS |
| Housing: | ABS | Application: | BOATS, Golf Carts, SUBMARINES, Electric Folklifts,solar Systems,RV |
| Module/Protocol: | Support Customization | OEM/ODM: | Support Customization |
| Port: | YANTIAN | ||
| High Light: | LifePO4 Deep Cycle Battery,Deep Cycle Battery 12V 200ah,RV Boat Lithium Ion Battery |
||
|
Product Name
|
12V 200AH Lithium ion battery
|
|
|
Model
|
200AH 12.8V
|
|
|
Electrical Specification
|
|
|
|
Chemical
|
Lithium iron phosphate
|
|
|
Nominal Voltage
|
12.8V
|
|
|
Nominal Capacity
|
200AH
|
|
|
Cell type
|
3.2V 6500mah
|
|
|
Configuration
|
4S32P
|
|
|
Energy
|
2560WH
|
|
|
Internal Resistance
|
≤80mΩ
|
|
|
Terminal Type
|
M8/M10
|
|
|
Dimension
|
520*238*218mm
|
|
|
Weight
|
Around 26kg
|
|
|
Charge and discharge specification
|
|
|
|
Charging Method
|
CC/CV
|
|
|
Standard Charging Voltage
|
14.6V
|
|
|
Recommended Charging Current
|
40A
|
|
|
Max. Charging Current
|
200A
|
|
|
Recommended Discharging Current
|
100A
|
|
|
Max. Discharging Current
|
200A
|
|
|
Pulse Discharge Current
|
300A/10S
|
|
|
Operating Temperature
|
|
|
|
Standard Charging Temperature
|
0~45℃
|
|
|
Standard Discharging Temperature
|
-20~55℃
|
|
|
Storage Temperature
|
-10~45℃
|
|
|
Notice:
If the 12V 200AH Lithium ion battery need be stored for a long time, Pls make sure at least one charge & discharge cycle every six months. |
|
|
|
12v 200ah lithium ion battery Cycle time and Warranty
|
|
|
|
Cycle life
|
4000
|
|
|
Warranty
|
24 months
|
|
