Product Details:
|
| Battery Type: | Lithium Ion, Lithium Ion Batteries | Capacity: | 12V 200AH/Support Customization |
|---|---|---|---|
| Cycle Life: | ≥ 2000 Cycle | Weighr: | 29KG/Support Customization |
| Application: | BOATS, Golf Carts, SUBMARINES, Electric Folklifts,solar Systems | OEM/ODM: | Support Customization |
| Port: | YANTIAN | ||
| High Light: | 12V 250ah Lithium Ion Battery,rechargeable solar battery Pack,200Ah lifepo4 car battery |
||
|
NO
|
Item
|
General Parameter
|
Remark
|
|
1
|
Model
|
3.2Ⅴ120Ah
|
Single
|
|
2
|
Casing material for single cell
|
Nickel plated steel
|
|
|
3
|
Standard capacity(0.2C5A)
|
200Ah
|
|
|
4
|
Rated voltage
|
12.8V
|
3.20V(Work voltage:3.20V)
|
|
5
|
Max.Charge voltage
|
14.6V
|
3.65V(Single Ave. charge Voltage)
|
|
6
|
Cut-off voltage
|
9.5V
|
2.50V(Single Ave. Discharge Voltage)
|
|
8
|
Standard charge current
|
100A
|
0.2C
|
|
9
|
charging Time
|
About 2.5h
|
|
|
10
|
Max Continuous discharge current
|
200A
|
1.17C
|
|
11
|
Peak discharge current
|
300A
|
2.1C10seconds
|
|
12
|
Battery dimension
|
525±1*270±1*220±1mm
|
|
|
13
|
(Approx.)Total weight(Approx.)
|
About 29kg
|
|
|
14
|
(Max, at 1000Hz.)Impedance(Max, at 1000Hz.)
|
≤ 20mΩ
|
|
|
15
|
(CC/CV)
Charge method (CC/CV) |
Standard
|
0℃~45℃
|
|
|
|
|
|
|
|
|
|
|
