Product Details:
|
| Long Life: | 15-20 Years | Usage: | Solar/wind/telecom |
|---|---|---|---|
| Application: | UPS/Solar System | Warranty: | 1~5 Years |
| High Light: | 100AH Yacht Battery,RV Yacht Battery,UPS lithium iron phosphate battery |
||
“FBC” battery are sold well all over the world,especially in Europe,America,Australia,India,Bangladesh etc.,We believe that our modern techniques and reasonable price will be the key to open your local market so that we can achieve win-win.
As the core brand is new Sustainable Energy Development, “FBC” embeds “Quality, Loyalty, Service and Development” and enjoys an excellent reputation i -n both domestic and global markets.
“FBC” is dedicated to providing the best batteries and services to customers from all parts of the world.
1. Application
Longer Cycle Life: Offers up to 20 times longer cycle life and five times longer float/ calendar life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.
Lighter Weight: About 40% of the weight of a comparable lead acid battery. A' drop in' replacement for lead acid batteries.
Higher Power: Delivers twice power of lead acid battery, even high discharge rate while maintaining high energy capacity.
Wider Temperature Range: -20℃~60℃
Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.
Increased Flexibility: Modular design enables deployment of up to four batteries in series and up to then batteries in parallel.
3. Technology
| Golf Cart Battery | |||
| Nominal Voltage | 48V/60V/72V | Battery Material | LFP/NCM |
| Discharge Current | 0.5C~1C | Charge Current | 0.5C~1C |
| Capacity | 8Ah/10Ah/16Ah/20Ah/25Ah/30Ah/40Ah/Customized | ||
| Full charged Voltage | LFP | 58.4V/76.6V/87.6V | |
| NCM | 54.6V/71.4V/84V | ||
| Discharge Cut-off Voltage | LFP | 40V/52.5V/60V | |
| NCM | 39V/51V/60V | ||
| Charge Temperature | 0℃ to 45℃ (32F to 113F) | ||
| Discharge Temperature | -20℃ to 55℃ (-4F to 131F) | ||
| Stroage Temperature | -10℃ to 45℃ (14F to 113F) | ||
| Cycle Life | >1000 cycles | ||
| Humidity | 60±25% Relative Humidity | Communication protocol | RS485 |
| Protection Functions | Built in Automatic Battery Protection System: | ||
| Automatic Low Voltage Disconnect | |||
| Automatic Short Circuit Protection | |||
| Automatic Over Voltage Protection | |||
| Automatic Over Current Protection | |||
| Automatic Internal Cell Balancing | |||
| Automatic Over Charge Protection | |||
| Automatic Over Discharge Protection | |||
| Automatic Over Temperature Protection | |||
| Display | LED indicator/display(Optional) | Customization | Dimension, Case color, Capacity, IP Rating, Function |
