Product Details:
|
| Battery Type: | LiFePO4, Lifepo4/lithium Battery | Cycle Life: | ≥ 2000 Cycle |
|---|---|---|---|
| Protection: | Built-in BMS | Weight: | 65KG |
| Size: | L:550*W:500*H:250(mm) | Warranty: | 3months-1year |
| Application: | RV,BOATS, Golf Carts, SUBMARINES, Electric Folklifts,solar Systems | OEM/ODM: | Support Customization |
| Port: | YANTIAN | ||
| High Light: | BMS Energy Storage Battery Pack,forklift Energy Storage Battery Pack,RV 72v 100ah lifepo4 battery pack |
||
|
Item
|
|
Parameters
|
Remark
|
|
|
Typical Capacity
|
|
120Ah
|
can be work in parallel
|
|
|
Nominal Voltage
|
|
72.0 V
|
25℃,Average Voltage at 0.2 C5A discharge
|
|
|
Charge current
|
|
Max30A
|
customrized
|
|
|
Charge cut-off voltage
|
|
840±0.50V
|
CC/CV
|
|
|
Charge time
|
|
5-6 hours
|
customrized
|
|
|
Working current
|
|
60A
|
customrized
|
|
|
Max working current(15S)
|
|
80A
|
customrized
|
|
|
Peak Working Current(2S)
|
|
100 A
|
customrized
|
|
|
Over current protection
|
|
300±10A
|
Cut off load or charge active
|
|
|
Over charge protection
|
|
4.25±0.025V
|
Single cell
|
|
|
Over discharge protection
|
|
2.8±0.025V
|
Single cell
|
|
|
Balance current
|
|
optional
|
|
|
|
Weight
|
|
40kg
|
shell of the metal
|
|
|
Storage temperature
|
|
≤1month
|
Best 20±5℃ for long-time storage
|
|
|
size
|
Length
|
435
|
Units: mm(customrized)——
|
|
|
|
Width
|
180
|
|
|
|
|
thick
|
220
|
|
|
