Product Details:
|
| Warranty: | 3months-1year | Anode Material: | LFP |
|---|---|---|---|
| Chargeable: | Yes | Application: | Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Folklifts, Electric Vehicles, Electric Wheelchairs, BOATS, Golf Carts, SUBMARINES Electric Folklifts,solar Systems |
| Weight: | 13.1, 13.1KG | The Charging Ratio: | 0.2~1C |
| The Discharge Rate: | 0.2~2C | Storage Type: | -10~45℃ |
| Battery Type: | Lithium Battery | Battery Size: | 12.8V 100AH |
| Terminal: | M8 | Protection Level: | IP55 |
| Battery Cell: | Lifepo4 | In Series And Parallel: | 7S17P |
| Cycle Life: | 4000 | ||
| High Light: | forklift lithium ion battery,motorcycle golf cart Battery,Lifepo4 golf cart Battery |
||
|
Electrical Characteristics |
Nominal Voltage
|
12.8v
|
|
|
Nominal Capacity
|
100Ah @ 0.2C
|
|
|
Energy
|
1280Wh
|
|
|
Internal resistance
|
≤45mΩ
|
|
|
Cycle Life
|
4000
|
|
|
Months Self discharge
|
≤3.5% per month at 25℃
|
|
Standard Charge |
Charge voltage
|
14.6±0.2V
|
|
|
Charge Mode( CC/CV) |
At 0℃~45℃ temperature, charged to 14.6v at constant current of 0.2C5A, and then, changed continuously with constant voltage of
14.6v until the current was not more than 0.02C5A |
|
|
Charge current
|
20A
|
|
|
Max.Charge current
|
50A
|
|
Standard Discharge |
Discharge current
|
20A
|
|
|
Max.continuous current
|
100A
|
|
|
Max. Pulse current
|
200A (<3S)
|
|
|
Discharge cut-off voltage
|
10.0V
|
|
Environmental |
Charge Temperature
|
0℃ to 45 ℃
|
|
|
Discharge Temperature
|
-20℃ to 60 ℃
|
|
|
Storage Temperature
|
0℃ to 45 ℃
|
|
|
Water Dust Resistance
|
IP55
|
|
Mechanical |
Cell & Method
|
IFR32700, 4S17P
|
|
|
Plastic Case
|
ABS
|
|
|
Dimension (L*W*H*TH)
|
328*172*220mm
|
|
|
Weight
|
Approx. 13.1KG
|
|
|
Terminal
|
M8
|
